The AIR Series handheld transmitters are light, compact and robust solutions, equipped with multi-function pushbuttons and a navigation menu to optimize functionality and settings according to the requested application.
They are available in two versions:
• with internal Li-Ion battery (A4, A6, A8) rechargeable through Docking Station;
• with two external Li-Ion batteries (A4B, A6B, A8B), battery charger and extractable power key switch kit for start-up which comes standard.
In both versions there is an "ID internal tx memory", which contains the unique and univocal address of the radio remote control along with the information that defines its mode of use. They can be combined with any AIR Series receiving unit.
Standard Kit Accessories
Battery charger or Docking Station for recharge
Heavy Duty Cover with belt
Available options
Charger Plug
Nest
USB adapter (with EU plugr)
Soft cover
Applications
| Power supply | 3,7 VDC (Li-ion) |
|---|---|
| Frequency band | 433.05-434.79 MHz (64 channels) 915-928 MHz (256 channels) |
| Hamming distance | ≥9 |
| Typical working range | 75-100 m |
| Average usage time with fully charged battery (continuous use at 20°C / 68°F) | 40 h |
| Safety performance of the STOP function (EN ISO 13849-1) | PL d |
| Protection degree | IP 65 (NEMA 4) |
| Operating and storage temperature | operating -20°C ÷ +55°C (-4°F ÷ +131°F) storage: -40°C ÷ +70°C (-40°F ÷ +158°F) |
| Dimensions | 64,5 x 179 x 37,5 mm 2.54 x 7.05 x 1.48 in |
| Weight | 0,25 kg 0.551 lb |
